Power Play 500 Series Deluxe Bingo Consoles

Featuring quality craftsmanship, Video King's PowerPlay” consoles are bingo at its best. Rich mahogany finish, durable shape and superior design, these deluxe consoles — with your choice of options —are highly versatile, yet affordable.

Standard Features:

•15-inch monitor and built in speakers. USB keyboard and mouse
•Windows 10 Operating System. Video flashboard software
•Verifies all Video King perms, most other manufacturers
•Removable motor/base for easy maintenance
•NTSC camera for live ball image
•Ability to save/store sessions
•Programmable timer with visual/audible signals
•30-month warranty on PC
•Automatic prize calculations when multiple winners
•Low-sound emissions
•Ability for remote access

(Team Viewer router sold separately)

Technical Specs

• 2“B“Data outputs, 2 Payout Data outputs, 2 Bonanza Bingo“R”Data outputs off of I/O board
• Supports Video King“B”Data flash-boards, including 4,000, 6000, 7000,
7500, 7600, multi-media series
• Parallel port to approved printers
• 1 RJ1 1 modem jack for remote service dial-up connection
• 1 JR45 Ethernet port for connection to local area network for OMNI
• 2 RCA line level audio inputs for audio mixing/multimedia
• 2 RCA line level outputs to connect to audio system/monitor speakers
• A 1/4-inch microphone input jack for caller audio equipment
• J ATI video graphics card for crystal
• clear caller and hall video displays
• J NTSC video output to connect to video equipment displaying live ball image and switching to card verification image

Software Features

• Compatible with OMNI” bingo management system, e-BOS* gaming systems, including our fixed-base systems, handheld bingo devices
• Integrated video flashboard capability
• Integrated presentation software for“in-hall"advertising
• Single“F"key operation for ease of use/speed of operation F keys provide shortcuts.F1 key turns on blower
• Windows-based PowerEdit™ game program editor
• Picture-in-picture for live ball image on game screen
• Remote access software for program changes/troubleshooting
• Password protected for added security
• Supports complex pattern definitions, including multi-level and multi-card sheet patterns

 Optional Features

• “A”Data,Old“A”Data & Micro Data signal translator for connection to “A”Data style flashboards for com- patibility to competitors’boards
• Software-controlled video switch for enhanced multi-media control
• Touch-screen interface
• Black laminate cabinet
• Random number generator
• RF modulator allows video signal to go out to monitors for ball image and verification

Select Features

• PowerPlay Console With Standard Monitor/NTSC Camera
Part No: 18PPLAY500PL
• PowerPlay Console With Touch-Screen Monitor/NTSC Camera
Part No: 18PPLAYS02PL
• PowerPlay Console With Touch-Screen Monitor/RF Modulator
Part No: 18PPLAY503PL
• Black Hawk II - Black Laminate. PowerPlay Console/Flat-Screen TV/Touch-Screen Monitor/NTSC Camera. Part No: I8PPLAY505BLT
• Black Hawk I — Black Laminate Finish. PowerPlay Console/
Touch-Screen Monitor /NTSC Camera. Part No: 18PPLAY505BL

Dimensions

• Shipping Weight: 330
• Shipping Dimensions: 69”L x 31”W x 47”H
• Dimensions: 62“L x 24”W x 33“H

Gaming and gamingdevices may or may not be approved in all jurisdictions. Please contact your sales representative to see what products ae allowed within your marketplace.
